ANEMOMETER / AIR VELOCITY CALIBRATION STANDARD EN-AVCS

EN-AVCS Download pdf

ANEMOMETER / AIR VELOCITY CALIBRATION STANDARD , Model No. : EN-AVCS , Make : ENRICO , Supply Includes :- Centrifugal Air Blower – 01 No. , Three Phase Drive – 01 No. , Pitot Tube ( 0.6mtr. ) – 01 No. , Differential Pressure Measuring Instrument ( Testo-510 ) – 01 No.

ANEMOMETER / AIR VELOCITY CALIBRATION STANDARD , Model No. : EN-AVCS , Make : ENRICO , Supply Includes :- Centrifugal Air Blower – 01 No. , Three Phase Drive – 01 No. , Pitot Tube ( 0.6mtr. ) – 01 No. , Differential Pressure Measuring Instrument ( Testo-510 ) – 01 No.

Technical Specifications

Centrifugal Air Blower Complete Unit With Electric Motor Specifications
Construction MS
Suction Size 250mm.
Delivery Size ( 250 X 190 )mm.
Capacity 2,500m³/hr
Pressure 200mmWG
Power 3HP , 2800RPM , 3Phase
Damper for Suction Line , Dia. – 300mm.
Ducting , Dia. – 300mm. , Length – 2,500mm. Approx.
